950~2400MHz DVB-S
HDBS-4000DW DWDM transceiver
4 Ways SAT-IF DWDM Optical transceiver L-Band Receiver
Product feature
1. Adopt DWDM, C-Band, 100GHz, ITU standard wavelength, one fiber bear to transmit 4 ways, 8 ways, 16 ways and 32 ways SAT-IF optical signal.
2. Use EDFA amplifier, realize the long distance and large-scale FTTH.
3. Compatible with any FTTx PON technology. Triple-play compatible with DBS.
4.1RU standard chassis, combine 4 unit SAT-IF optical transmitter or optical receiver.
5. HDBS-4100 adopts 19" standard chassis, LCD in the front panel display the device status and fault diagnosis, standard RS232 communication interface, SNMP network management function.
6. HDBS-4200DW-RX adopt small size metal casing, convenient to connect to Multiswitch to STB.
7. HDBS-4200DW-RW is applied to FTTx PON, realize the seamless link with ONU of EPON, GPON.
8. High linearity, with cooling DFB laser, 1550nm ITU wavelength ± 1.6nm tunable.
9. Optical transmitter output power 0 ~ -3dBm adjustable, applies to DWDM.
10. TG type optical transmitter (standard configuration), build-in high linearity AGC amplification.
11. TO type optical transmitter (option configuration), without build-in IF amplification, allow high level input, applies to L-Band
12. Modem with high output level.
13. All 4 ways optical transmitter are able to supply +13VDC or +18VDC to LNB.
Main application
1. Satellite long distance, large-scale fiber optic distribution system
2. FTTx PON
3. Satellite L-Band long distance uplink/downlink fiber optic link
HDBS-4000DW DWDM transceiver
4 Ways SAT-IF DWDM Optical transceiver L-Band Receiver
Product feature
1. Adopt DWDM, C-Band, 100GHz, ITU standard wavelength, one fiber bear to transmit 4 ways, 8 ways, 16 ways and 32 ways SAT-IF optical signal.
2. Use EDFA amplifier, realize the long distance and large-scale FTTH.
3. Compatible with any FTTx PON technology. Triple-play compatible with DBS.
4.1RU standard chassis, combine 4 unit SAT-IF optical transmitter or optical receiver.
5. HDBS-4100 adopts 19" standard chassis, LCD in the front panel display the device status and fault diagnosis, standard RS232 communication interface, SNMP network management function.
6. HDBS-4200DW-RX adopt small size metal casing, convenient to connect to Multiswitch to STB.
7. HDBS-4200DW-RW is applied to FTTx PON, realize the seamless link with ONU of EPON, GPON.
8. High linearity, with cooling DFB laser, 1550nm ITU wavelength ± 1.6nm tunable.
9. Optical transmitter output power 0 ~ -3dBm adjustable, applies to DWDM.
10. TG type optical transmitter (standard configuration), build-in high linearity AGC amplification.
11. TO type optical transmitter (option configuration), without build-in IF amplification, allow high level input, applies to L-Band
12. Modem with high output level.
13. All 4 ways optical transmitter are able to supply +13VDC or +18VDC to LNB.
Main application
1. Satellite long distance, large-scale fiber optic distribution system
2. FTTx PON
3. Satellite L-Band long distance uplink/downlink fiber optic link
| Performance | Index | Supplement | |||
| TX&RX optical feature | Operating wavelength | (nm) | 1528~1563 | 100GHz, ITU standard wavelength | |
| Wavelength adjustable range | (nm) | ±1.6 | ±200GHz | ||
| Wavelength adjustable mode | ±0.05nm stepping | ||||
| Wavelength stability | (pm/º C) | -1~0 | TC=20~70º C | ||
| Side mode suppression ratio | (dB) | >45 | SMSR | ||
| Equivalent noise intensity | (dB/Hz) | ≤-160 | 20~1000MHz(CATV) | ||
| ≤-145 | 20~2700MHz(SAT-IF) | ||||
| Number of TX output port | 1 | HDBS-4105CW1 | |||
| 4 | HDBS-4105CW4 | ||||
| TX output power 1) | (dBm) | 6.0 (4mW) | HDBS-4106DW-TX | ||
| 8.0 (6mW) | HDBS-4108DW-TX | ||||
| 10.0 (10mW) | HDBS-4110DW-TX | ||||
| Number of RX output port | 1 | HDBS-4113DW1 | |||
| 4 | HDBS-4113DW4 | ||||
| RX responsibility | (A/W) | ≥0.9 | 1550nm | ||
| RX input power 1) | (dBm) | 0 ~ -13 | |||
| Number of RX input port | 1 | RW (for ONU) | |||
| Return loss | (dB) | ≥50 | |||
| Optical connector | SC/APC | Option FC/APC, LC/APC | |||
| Laser type | Cooling DFB | TX with ISO | |||
| Optical receive tube type | PIN | RX | |||
| SAT-IF feature | Operating bandwidth | (MHz) | 950~2400 | ||
| TX input level | (dBmV) | -25 ~ -14 | TX with AGC | ||
| RX output level | (dBmV) | -15 ~ -40 | RX | ||
| Flatness | (dB) | 0.5 | 40MHz | ||
| ±1.0 | 950~2400MHz | ||||
| Input impedance | (Ω) | 75 | |||
| RF return loss | (dB) | 12 | |||
| RF connector | F-female | ||||
| C/IM3 2) | (dB) | ≥55 | |||
| Equivalent noise intensity | (dB/Hz) | >115 | |||
| Link gain 3) | (dB) | 25 | |||
| General feature | Serial interface | RS232 | |||
| SNMP network management interface | RJ45 | ||||
| Power supply | (V) | 95~260VAC | |||
| Power consume | (W) | 50 | |||
| Operating temp. | (º C) | -5 ~ +65 | |||
| Relative humidity | (%) | <85 | |||
| Size (W)×(D)×(H) | HDBS-4100 | 19×10.5×1.75 ( " ) 483×267×44 ( mm ) | |||
| HDBS-4200 | 10.4×7.8×1.38 ( " ) 263×198×35 ( mm ) | ||||
