HP Compatible 1.25g Single Mode Bidi Optical Transceiver 80km
HP Compatible 1.25g single mode Bidi optical transceiver 80km1.DescriptionThe SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 80KM transmission distance with SMF.The transceiver consists of three sections: a DFB laser transmitte......
Send Inquiry
Product Description
HP Compatible 1.25g single mode Bidi optical transceiver 80km
1.Description
The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 80KM transmission distance with SMF.
The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.
2.Features
1.Dual data rate of 1.25Gbps/1.063Gbps operation;
2.1490nm DFB laser andPIN photodetector for80km transmission; 3.Compliant with SFP MSA and SFF-8472 withsimplex LC receptacle;
4.Digital Diagnostic Monitoring: Internal Calibration or External Calibration; 5.Compatible with RoHS;
6.+3.3V single power supply;
7.Operating case temperature:
Standard : 0 to +70 degree
3.Application
1.Gigabit Ethernet;
2.Fiber Channel;
3.Switch to Switch interface;
4.Switched backplane applications;
5. Router/Server interface;
6.Other optical transmission systems;
4.Paremeter
5.Why choose Takfly SFP module?
1.Our SFP module can be produced compatible with Cisco, Juniper, Dell, HP, 3 COM, Juniper, Huawei, etc.
2.Made of 100% new components (Tosa and Rosa) imported from Japan;
3.The actual transmitter distance of our module is same as we promise to you;
4.3 years warranty;
6.Warm tip:
To aviod strong lighting will burn out 60-80km sfp module during testing, pls kindly add 10dB attenuator or 40km bare fiber before your testing.
7.Our SFP module outlook
8.TAKFLY SFP module family
9.TAKFLY workshop
10.Our exhibition.
Each year Takfly will attend 5 or 6 international fairs, like: OFC, SVIAZ EXPO COMM MOSCOW, COMMUNICASIS, ECOC and NETCOM BRAZIL.
11.Company Information
Takfly, established in 2000, has been manufacturing and exporting fiber cable, adapter, attenuator, connector, coupler, splitter, termination box, ODF, fiber instruments, media conceiver, switch, optical module, CWDM/DWDM, etc. Takfly's products have passed the management verification: ISO14001: 2004. and goods have passed RoHS, CE, FCC, REACH, EN50575, ISO9001, etc.
So far, Our products have been widely installed in many big worldwide project and work perfectly. Many project contactors ask the first and second operators to purchase fiber items from Takfly for their new project. In addition, we also have builted long term cooperation with Lapp, Amper, Telefonica, orange and Ericsson. All enquiry are warmly welcomed here no matter it's small or big, we promise to provide all customers high quality and good price item.
Any interest, you can contact Sophie at any time, and our technical data and samples can be provided without delay.
1.Description
The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 80KM transmission distance with SMF.
The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.
2.Features
1.Dual data rate of 1.25Gbps/1.063Gbps operation;
2.1490nm DFB laser andPIN photodetector for80km transmission; 3.Compliant with SFP MSA and SFF-8472 withsimplex LC receptacle;
4.Digital Diagnostic Monitoring: Internal Calibration or External Calibration; 5.Compatible with RoHS;
6.+3.3V single power supply;
7.Operating case temperature:
Standard : 0 to +70 degree
3.Application
1.Gigabit Ethernet;
2.Fiber Channel;
3.Switch to Switch interface;
4.Switched backplane applications;
5. Router/Server interface;
6.Other optical transmission systems;
4.Paremeter
| HP Compatible | SFP-1G-BXU | Vendor Name | TAKFLY |
| Receiver Sensitivity | <-10.3dBm | Max Data Rate | 1.25Gbps |
| Wavelength | TX:1490/RX:1550nm and TX:1550/RX:1490nm | Max Cable Distance | 80km |
| Interface | LC simplex | Optical Components | VCSEL TX:1490/RX:1550nm and TX:1550/RX:1490nm |
| Cable Type | SMF | DOM Support | Yes |
| Protocols | MSA and SFF-8472 Compliant | Commercial Temperature Range | 0 to 70°C |
5.Why choose Takfly SFP module?
1.Our SFP module can be produced compatible with Cisco, Juniper, Dell, HP, 3 COM, Juniper, Huawei, etc.
2.Made of 100% new components (Tosa and Rosa) imported from Japan;
3.The actual transmitter distance of our module is same as we promise to you;
4.3 years warranty;
6.Warm tip:
To aviod strong lighting will burn out 60-80km sfp module during testing, pls kindly add 10dB attenuator or 40km bare fiber before your testing.
7.Our SFP module outlook
8.TAKFLY SFP module family
9.TAKFLY workshop
10.Our exhibition.
Each year Takfly will attend 5 or 6 international fairs, like: OFC, SVIAZ EXPO COMM MOSCOW, COMMUNICASIS, ECOC and NETCOM BRAZIL.
11.Company Information
Takfly, established in 2000, has been manufacturing and exporting fiber cable, adapter, attenuator, connector, coupler, splitter, termination box, ODF, fiber instruments, media conceiver, switch, optical module, CWDM/DWDM, etc. Takfly's products have passed the management verification: ISO14001: 2004. and goods have passed RoHS, CE, FCC, REACH, EN50575, ISO9001, etc.
So far, Our products have been widely installed in many big worldwide project and work perfectly. Many project contactors ask the first and second operators to purchase fiber items from Takfly for their new project. In addition, we also have builted long term cooperation with Lapp, Amper, Telefonica, orange and Ericsson. All enquiry are warmly welcomed here no matter it's small or big, we promise to provide all customers high quality and good price item.
Any interest, you can contact Sophie at any time, and our technical data and samples can be provided without delay.
Our sfp module can be produced compatible with HP, CSICO, HUAWEI, H3C and other devices. For more detail sfp module info, pls do not hesitate to contact me. In addition, your trial order is warmly welcomed here!
