Eoc Slave Eoc Master Gpon ONU Receiver 3 En 1

★Description
EOC Master+ONU+Receiver (All-In-One) (DT-OEC-MOR97),Main Functional: (ONU:1 x GPON ONU)+(EOC Master:2*EOC Master)+(CATV:1x CATV Optical Receiver),External Interface: (Fiber Port:5/8" type, 2 port, for Fiber Optic Pigtail input,COM Port:F-Type female, 4 output port for mixed EOC and CATV signal,
Power Input Port:F-Type female, line power(40-90VAC) input version,Power cord, Mains Powered (90-264VAC) version),Uplink:(Broadcast CATV:1*CATV optical, SC/UPC),(Ethernet Data:1*GPON Class B+, SC/PC),GPON:(Standard compliance:ITU-T G.984.X),(Optical Interface:1 x GPON CLASS B+, SC/PC),
(Transmission Rate:Upstream: 1.244Gbps, Downstream: 2.488Gbps),
(Transmission Distance:20Km@1:128),(Wavelength:Upstream 1310nm, Downstream 1490nm),RF Specifications:(Bandwidth:45~860 MHz),(Nominal RF Output Level:104dBuV),(Return Loss:≥14 dB),Optical and temperature AGC:
Stability of RF Level under optical AGC:≤±1 dB,AGC Scope:-6 ~ 0dBm,Power supply:AC90V~264V OR Cable Power 60V,European standard power plug OR American standard power plug.

★Features
Standards
⊙Complies with GPON G.984 standards
⊙Complies with HomePlug AV international standards and IEEE 1901 Standard

Product Configuration
⊙RF output configurations with 4 outputs
⊙Configurations available with 1 GPON ONU module
⊙Configurations available with 1 HFC Optical Receiver
⊙Configurations available with 2 HomePlug AV EOC Master modules
⊙35/47, 42/54, 65/87 type High/Low Filter optional to meet your network
⊙Line Power (from 90 to 264 VAC) or Cable Line Power (60VAC) optional

CATV RF Features
⊙Supports higher RF output: 104dBuv
⊙AGC (from -6 to 0dBm) function for stable RF output

Data Transportation in Coaxial Cable
⊙Recommend 40~50dB link loss for about 300 throughput
⊙Supports Max link loss greater than 85 dB (40Mbps throughput in lab)
⊙Supports data throughput of greater than 300 Mbps per EOC Master module

Network Management
⊙CLI, WEB management for ONU module
⊙WEB, SNMP management for EOC module
⊙Optical Receiver status monitor and control by PON system

Other Features
⊙Line Power 60AC feed in and out
⊙019C Housing, aluminum alloy die casting shaping

★Specification

Item	Parameters	Specification
Main Functional Module Configuration	ONU	1 x GPON ONU
	EOC Master	2*EOC Master
	CATV	x CATV Optical Receiver
External Interface	Fiber Port	5/8" type, 2 port, for Fiber Optic Pigtail input
	COM Port	F-Type female, 4 output port for mixed EOC and CATV signal
	Power Input Port	F-Type female, line power(40-90VAC) input version
	Power Input Port	Power cord with China plug, Mains Powered (90-264VAC) version
Uplink	Broadcast CATV	1*CATV optical, SC/UPC
Uplink	Ethernet Data	1*GPON Class B+, SC/PC
Specification of ONU Parts
GPON	Standard compliance	ITU-T G.984.X
	Optical Interface	1 x GPON CLASS B+, SC/PC
	Transmission Rate	Upstream: 1.244Gbps, Downstream: 2.488Gbps
	Transmission Distance	20Km@1:128
	Optical Fiber Type	9/125um, Single Mode, Single Fiber
	Wavelength	Upstream 1310nm, Downstream 1490nm
	Optical Power Tx	+0.5dBm to +5dBm(Class B+), +0.5dBm to +5dBm(Class C+)
	Receiving Sensitivity	-27 dBm(Class B+), -30 dBm(Class C+)
Indicator	Indicator Description	PWR: Power up or down PON:ONU registered LOS: Optical Link Status SYS: system work indicator
Network Management	Management Mode	Support ITU-T G.984.X OMCI (GPON) Support WEB management Suppoort Telnet Management
Network Management	Function	Status monitor, Configuration management, Alarm management, Log management
Specification of OR
Optical Specifications	Wavelength	1550±10 nm
	Optical Power Input Range	-10 ~ +2 dBm
	Recommend optical Power Input Range	-6 ~ 0dBm
	Optical Input Return Loss	>45 dB
RF Specifications	Bandwidth	45~860 MHz
	Flatness	≤±1.5 dB
	Nominal RF Output Level	104dBuV
	Impedance	75 Ohm
	Return Loss	≥14 dB
	CNR	≥51 dB
	CSO	≥60 dBc
	CTB	≥60 dBc
	Note: CNR, CSO, CTB parameter testing environment is in1550nm directly modulation transmitter, optical input -1dBm,OMI=3.2%, 59CH PAL-D signal load.
Optical and temperature AGC	Stability of RF Level under optical AGC	≤±1 dB
Optical and temperature AGC	AGC Scope	-6 ~ 0dBm
LED Indicator	Indicator Description	TV1: Status of Output 1 of optical receiver module TV2: Status of Output 2 of optical receiver module OPT-M: Optical power is nominal OPT-L: Optical power is abnormal PWR: Power Supply Status
Specification of EOC Master
Interface	Inband Management Port	1 * 10/100/1000M auto-negotiation, RJ45
LED Indicator	LED Indicator	PWR: Power Supply Status CAB1: CABLE Link Status indicator1 CAB2: CABLE Link Status indicator2
Performance Parameters	RF Parameters	Frequency Band :7.5-65MHz RF Output Level: 115±5dBuv @4 RF output port Receive sensitivity: 45dBuv
	Transmission	PHY Layer: 600Mbps Throughput on MAC Layer: 320Mbps
	Modulation Mode	OFDM2690 carriers, 4096/1024/256/64/16/8 QAM, QPSK, BPSK, ROBO
	Working Mode	TDMA/CSMA
	Encryption Mode	AES-128
Standard	EOC Standard	IEEE P1901(Draft) , HomePlug AV
Standard	Ethernet Standard	IEEE 802.3, IEEE 802.3x, IEEE 802.3u IEEE802.1P, IEEE802.1Q
Software	Network Management	WEB, CLI, SNMP
Software	Software Features	VLAN, QOS, Bandwidth Control, Broadcast storm limitation
Physical Features
Physical Features	Power supply	Line Power(90-264VAC) Cable power(60VAC) optional
	Power Consumption	Consumption:<80 W
	Net weight	3.7kg
	Environment Attribute	Working Temperature:-20 ~ 65ºC Storage Temperature:-40 ~ 85ºC Working humidity:10% ~ 90%non-condensing Storage humidity:10% ~ 90% non-condensing

★Typical Application

⊙ CATV
⊙ Internet Access
⊙ VOD
⊙ IPTV
⊙ Camera monitor system

★Order Information

Product	Item	Description
EOC All-In-One (ONU+OR+2*EOC)	DT-OEC-MOR97	Built-in one GPON ONU Module, one OR module and two 74 series chipset EOC Modules; one GPON uplink port, one CATV optical input, four TV+data mixed output port, CATV RF output 104dBuv@each port, Outdoor waterproof designed. 90-264VAC power supply or 60VAC Cable line power supply feed in and out optional, 65/87 H/L filter is default, 35/47, 42/54 H/L filter is optional.
