Qsfp-40g-Lr4 Huawei 40ge Qsfp+ Optical Modules 02310mhs
QSFP-40G-LR4 Huawei 40GE QSFP+ Optical Modules 02310MHSTechnical specificationsItemDescriptionTransceiver form factorQSFP+Transmission speed40GECenter wavelength (nm)1271, 1291, 1311, 1331Standards compliance40GBASE-LR4Connector typeLCApplicable cable and maximum transmission distanceSingle-mode fib......
Send Inquiry
Product Description
QSFP-40G-LR4 Huawei 40GE QSFP+ Optical Modules 02310MHS
Technical specifications
Technical specifications
| Item | Description |
| Transceiver form factor | QSFP+ |
| Transmission speed | 40GE |
| Center wavelength (nm) | 1271, 1291, 1311, 1331 |
| Standards compliance | 40GBASE-LR4 |
| Connector type | LC |
| Applicable cable and maximum transmission distance | Single-mode fiber: 10 km |
| Transmit power (dBm) | -7.0 to +2.3 |
| Maximum receiver sensitivity (dBm) | -11.5 |
| Overload power (dBm) | 3.3 |
| Extinction ratio (dB) | 3.5 |
| Operating temperature | 0°C to 70°C (32°F to 158°F) |
| Part number | 02310MHS |
| Huawei FE SFP/eSFP Optical Modules | |
| Model No. | Part No. |
| SFP-FE-SX-MM1310 | 02315233 |
| eSFP-FE-LX-SM1310 | 02315205 |
| S-SFP-FE-LH40-SM1310 | 02317344 |
| S-SFP-FE-LH80-SM1550 | 02317345 |
| SFP-FE-LX-SM1310-BIDI | 02315203 |
| SFP-FE-LX-SM1550-BIDI | 02315202 |
| Huawei GE eSFP Optical Modules | |
| eSFP-GE-SX-MM850 | 02315204 |
| SFP-GE-SX-C | 02312UUB |
| SFP-GE-LX-SM1310 | 02315200 |
| SFP-GE-LX10-C | 02312UUC |
| S-SFP-GE-LH40-SM1310 | 02317346 |
| SFP-GE-EX-C | 02312UUD |
| S-SFP-GE-LH40-SM1550 | 02317347 |
| S-SFP-GE-LH80-SM1550 | 02317348 |
| eSFP-GE-ZX100-SM1550 | 02315206 |
| SFP-GE-LX-SM1310-BIDI | 02315285 |
| SFP-GE-LX-SM1490-BIDI | 02315286 |
| LE2MGSC40DE0 | 02310KVV |
| LE2MGSC40ED0 | 02310KVU |
| SFP-GE-ZBXD1 | 02311DDB |
| SFP-GE-ZBXU1 | 02311DDC |
| SFP-GE-BXU1-SC | 02310TQH |
| Huawei GE CSFP Optical Modules | |
| CSFP-GE-FE-BXD1 | 02310TEE |
| CSFP-GE-FE-BIDI2 | 02310WRR |
| CSFP-GE-FE-BIDI4 | 02310XQV |
| Huawei GE-CWDM eSFP Optical Modules | |
| CWDM-SFPGE-1471 | 02310LPN |
| CWDM-SFPGE-1491 | 02310LPK |
| CWDM-SFPGE-1511 | 02310LPH |
| CWDM-SFPGE-1531 | 02310LPL |
| CWDM-SFPGE-1551 | 02312AXN |
| CWDM-SFPGE-1571 | 02312AXM |
| CWDM-SFPGE-1591 | 02312AXK |
| CWDM-SFPGE-1611 | 02310LPJ |
| Huawei 10GE SFP+ Optical Modules | |
| SFP-10G-USR | 02310MNW |
| OSXD22N00 | 02310CRM |
| OMXD30000 | 02318169 |
| SFP-10G-SR-C | 02312UUE |
| SFP-10G-iLR | 02311BJJ |
| SFP-10G-iLR-C | 02312UUF |
| OSX010000 | 02318170 |
| SFP-10G-LR-C | 02312UUG |
| OSX040N01 | 02310CNF |
| SFP-10G-ER-C | 02312UUH |
| SFP-10G-ER-1310 | 02311RLX |
| SFP-10G-ZR | 02310SNN |
| SFP-10G-BXU1 | 02310QBJ |
| SFP-10G-BXD1 | 02310QDT |
| SFP-10G-ER-SM1330-BIDI | 02311BJB |
| SFP-10G-ER-SM1270-BIDI | 02311BJC |
| Huawei 10GE-CWDM SFP+ Optical Modules | |
| SFP-10G-ZCW1471 | 02310SSG |
| SFP-10G-ZCW1491 | 02310SSF |
| SFP-10G-ZCW1511 | 02310SSE |
| SFP-10G-ZCW1531 | 02310SSD |
| SFP-10G-ZCW1551 | 02310SSC |
| SFP-10G-ZCW1571 | 02310SSB |
| SFP-10G-ZCW1591 | 02310SSA |
| SFP-10G-ZCW1611 | 02310SRY |
| Huawei 40GE QSFP+ Optical Modules | |
| QSFP-40G-SR4 | 02310MHQ |
| QSFP-40G-iSR4 | 02310MHR |
| QSFP-40G-eSR4 | 02310RMB |
| QSFP-40G-iSM4 | 02311DRW |
| QSFP-40G-eSM4 | 02311DTR |
| QSFP-40G-LX4 | 02311HNP |
| QSFP-40G-LR4 | 02310MHS |
| QSFP-40G-ER4 | 02311BKT |
| QSFP-40G-SR-BD | 02311FPA |
| QSFP-40G-SDLC-PAM | 02311PUU |
| QSFP-40G-eSDLC-PAM | 02311QTR |
| Huawei Industrial Optical Modules | |
| OGSM01880 | 02310LJG |
| OGSC10DD0 | 02310LJH |
| OGSC40DD0 | 02310LJJ |
| SFP+10GE-LH10-SM1310 | 02311MUU |
| SFP-10G-SR | 02311SKW |
| SFP-10G-iLR | 02311BJJ |
| SFP-10G-iLR-C | 02312UUF |
| SFP-10G-BXU1 | 02310QBJ |
| SFP-10G-BXD1 | 02310QDT |
| SFP-GE-BX-D1-I | 02311DMA |
| SFP-GE-BX-U1-I | 02311DMF |
| SFP-GE-BX40-U-I | 02312TMB |
| SFP-GE-BX40-D-I | 02312TMC |
| Huawei 100GE QSFP28 Optical Modules | |
| QSFP28-100G-LR4 | 02311KNU |
| QSFP28-100G-PSM4 | 02311MNM |
| QSFP28-100G-SR4 | 02311GBW |
| QSFP-100G-eSR4 | 02311PSH |
| QSFP-100G-CLR4 | 02311MNP |
| QSFP-100G-CWDM4 | 02311MNN |
| QSFP-100G-ER4-Lite | 02311YXR |
| GE-DWDM eSFP Optical Module | |
| DWDM-SFPGE-1560-61 | 02310LLE |
| GE SFP Copper Modules | |
| SFP-1000BaseT | 02314171 |
| SFP Stack Optical Modules | |
| SFP-6GE-LR | 02310SRD |
| 10GE-DWDM SFP+ Optical Modules | |
| SFP-10G-ZDWT | 02310YUT |
| 25GE SFP28 Optical Modules | |
| SFP-25G-LR | 02312LSE |
| SFP-25G-SR | 02311KNR |
| GPON Optical Modules | |
| H87MMA5671A2 | 03031QHU |
| Optical Modules Dedicated for Hybrid Cables | |
| SFP-10G-iLR-S | 02313CBJ |
| Huawei GE-CWDM eSFP Optical Modules (Used Only in the OADM scenario) | |
| CWDM-SFPGE-1271 | 02312AXC |
| CWDM-SFPGE-1291 | 02312AXB |
| CWDM-SFPGE-1311 | 02312AXA |
| CWDM-SFPGE-1331 | 02312AWY |
| CWDM-SFPGE-1351 | 02312AWX |
| CWDM-SFPGE-1371 | 02312AWW |
| CWDM-SFPGE-1391 | 02312AWV |
| CWDM-SFPGE-1411 | 02312AWU |
| CWDM-SFPGE-1431 | 02312AWT |
| CWDM-SFPGE-1451 | 02312AWS |
| Others | |
| If you didn't find the module you need pls contact us at any time. | |
