Polarization Isensitive Dual Stage Fiber Optical Isolator 1310/1480/ 1550 Nm
Polarization-Insensitive Single/Dual Stage Optical IsolatorDescriptionAn optical isolator is a passive magneto-optic device that only allows light to travel in one direction. Isolators are used to protect a source from back reflections or signals that may occur after the isolator. Back reflections c......
Send Inquiry
Product Description
Polarization-Insensitive Single/Dual Stage Optical Isolator
Order Information:
Description
An optical isolator is a passive magneto-optic device that only allows light to travel in one direction. Isolators are used to protect a source from back reflections or signals that may occur after the isolator. Back reflections can damage a laser source or cause it to mode hop, amplitude modulate, or frequency shift. In high-power applications, back reflections can cause instabilities and power spikes.Optical isolators are also known as optoisolators, optocouplers and photocouplers.
Features
High Isolation
Low Insertion Loss
High Return Loss
Low Polarization Sensitivity
Applications
Optical Fiber Amplifiers
CATV Fiber optic Links
Fiber optic Systems Testing
Fiber optic LAN Systems
Fiber Laser
Specifications
1. ALL specification include the effect of all states of polarization.
2. Values referenced without connectors,insertion loss for a connector-pair is 0.20dB to 0.30dB.
An optical isolator is a passive magneto-optic device that only allows light to travel in one direction. Isolators are used to protect a source from back reflections or signals that may occur after the isolator. Back reflections can damage a laser source or cause it to mode hop, amplitude modulate, or frequency shift. In high-power applications, back reflections can cause instabilities and power spikes.Optical isolators are also known as optoisolators, optocouplers and photocouplers.
Features
High Isolation
Low Insertion Loss
High Return Loss
Low Polarization Sensitivity
Applications
Optical Fiber Amplifiers
CATV Fiber optic Links
Fiber optic Systems Testing
Fiber optic LAN Systems
Fiber Laser
Specifications
| Parameters | Unit | Single Stage | Dual Stage |
| Operating Wavelength | nm | 1310,1480,1550,1600 | |
| Typical Peak Isolation | dB | ≥40 | ≥55 |
| Minimum Isolation | dB | ≥30 | ≥40 |
| Typical Insertion Loss | dB | ≤0.5 | ≤0.6 |
| Maximum Insertion Loss | dB | ≤0.6 | ≤0.8 |
| PDL | dB | ≤0.05 | ≤0.1 |
| PDM | Ps | ≤0.25 | ≤0.05 |
| Bandwidth | nm | ±20nm | ±30nm |
| Return Loss | dB | ≥55 | ≥55 |
| Maximum Power Handing | mW | 300 | |
| Operating Temperature | ºC | 0~+70 | |
| Storage Temperature | ºC | -40~+85 | |
2. Values referenced without connectors,insertion loss for a connector-pair is 0.20dB to 0.30dB.
Order Information:
| Isolator Type | Wavelength | Fiber Type | Package | Pigtail Type | Fiber Length | In/Out Connector |
| IS=Single stage IU=Dual stage | 13=1310nm 14=1480nm 15=1550nm LB=L Band | 1=G652D 2= G657A1 | C2=5.5X30mm Steel Tube B8=3.0x25mm Steel Tube D=90X20X9.5mm Plastic Box | B=0.25mm Bare Fiber L=900um S=2.0mm R=3.0mm | 10=1.0m 15=1.5m 20=2.0m | 00=None FA=FC/APC FU=FC/UPC SA=SC/APC SU=SC/UPC ST=ST/PC LU=LC/UPC LA=LC/APC |
--------------------------------------------------FAQ--------------------------------------------------
Q1. Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for the product?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our formal products.
Q7: What action will you take if there are some product problems?
A: If there are defective ones in the batch of products, we will offer spare ones for.
Q1. Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for the product?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our formal products.
Q7: What action will you take if there are some product problems?
A: If there are defective ones in the batch of products, we will offer spare ones for.
