Ola- 1550 2-Way Outdoor AGC Fiber Optical CATV Node Receiver
Outdoor Fiber Optical Receiver with AGCIt is a new high-class 2-way output CATV network optical receiver. The pre-amplifier adopts GaAs MMIC, post-amplifier adopts GaAs module. Optimized circuit design coordinate with rich design experience, the device achieve high performance index. Microprocessor ......
Send Inquiry
Product Description
Outdoor Fiber Optical Receiver with AGC
It is a new high-class 2-way output CATV network optical receiver. The pre-amplifier adopts GaAs MMIC, post-amplifier adopts GaAs module. Optimized circuit design coordinate with rich design experience, the device achieve high performance index. Microprocessor control, digital display the parameters that make the engineering debug very convenience. It is the main products to build CATV network.
| Outdoor Fiber Optical Receiver with AGC | |
| Item | Specification |
| Rated Output Level(dBμV) | ≥ 108 |
| Wavelength (nm) | 1550±10 |
| Fiber Connector | FC/APC SC/APC |
| Bandwidth(MHz) | 47~862 |
| Channels | 85 |
| C/N (dB) | ≥51 |
| CTB (dBm) | ≥65 |
| CSO (dBm) | ≥60 |
| RF In (dBuV) | 80±5 |
| Unflatness | ≤0.75 |
| Power loss (W) | ≤30 |
| Power Voltage (V) | 220V(110~254) |
