FTTH 2 Ports Fiber Optic Terminal Box with High Quality
FTTH 2 ports Fiber Optic Terminal box with high qualityDescription:Suitable for multi type module installation, application in the work area routing subsystem The embedded surface box, installation, convenient disassembly with protective door, dust; according to customer requirements can be printed ......
Send Inquiry
Product Description
FTTH 2 ports Fiber Optic Terminal box with high quality
Description:
Suitable for multi type module installation, application in the work area routing subsystem
The embedded surface box, installation, convenient disassembly with protective door, dust; according to customer requirements can be printed LOGO
Application of optical fiber with SC / LC simplex, duplex different environment bright dress, flush plate. A combination of all the modules can be according to customer selection and configuration
All modules are free welding mode
Usage range and Application:
The telecommunication network, metropolitan area network, optical fiber communication system
Optical fiber test instrument / meter
Optical fiber CATV, fiber optic sensor
Fiber broadband access network, FTTH fiber into the home
Optical fiber distribution frame, frame type and wall hung type optical fiber distribution unit
Specification:
Takfly worldwide Exhibition
Thank you for refer our products, should any question please feel free to contact me.
Description:
Suitable for multi type module installation, application in the work area routing subsystem
The embedded surface box, installation, convenient disassembly with protective door, dust; according to customer requirements can be printed LOGO
Application of optical fiber with SC / LC simplex, duplex different environment bright dress, flush plate. A combination of all the modules can be according to customer selection and configuration
All modules are free welding mode
Usage range and Application:
The telecommunication network, metropolitan area network, optical fiber communication system
Optical fiber test instrument / meter
Optical fiber CATV, fiber optic sensor
Fiber broadband access network, FTTH fiber into the home
Optical fiber distribution frame, frame type and wall hung type optical fiber distribution unit
Specification:
| item | Technical parameters |
| A*B*C(mm)appearance dimension | 86*86*24 |
| D(mm)wall mounting dimension | 60 |
| usage range | 3.0 x 2.0 mm indoor cable |
| fiber diameter | 125μm ( 652 & 657 ) |
| cladding diameter | 250μm & 900μm |
| Applicable mode | Single mode and multimode |
| Tensile strength | >50 N |
| temperature | -40~+85ºC |
| adapter | SC & FC |
| insertion loss | ≤0.2dB(1310nm & 1550nm) |
| output port | 2 |
Takfly worldwide Exhibition
Thank you for refer our products, should any question please feel free to contact me.
