1X3 3X3 Monolithic Fiber Multi-Mode Coupler
1x3 3x3 Monolithic Fiber Multi-Mode Coupler DescriptionFBT Coupler is a splitter which based on fused biconical taper technology. It is widely accepted and used in passive optical networks (PON) solution. FBT coupler is a traditional technology that two fibers are typically twisted and fused togethe......
Send Inquiry
Product Description
Description
FBT Coupler is a splitter which based on fused biconical taper technology. It is widely accepted and used in passive optical networks (PON) solution. FBT coupler is a traditional technology that two fibers are typically twisted and fused together while the assembly is being elongated and tapered.
Lightwit Photonics provides a wide breadth of FBT Coupler splitters, including Singlemode Standard Coupler, Dual Window Coupler, Three Window Coupler, Wide Band Coupler, PM Fused Coupler and All Band Coupler with low insertion loss and high performance. These Fused couplers are available with coupling ration ranging from 1:99 to 50:50. Most important, customized specs are also available.
Features
Low Insertion LossLow PDL
Various Coupling Ratios
Compact Size
Wide Operating Temperature
High Reliability and Stability
Applications
FTTx SolutionsLAN, WAN and Metro Networks
Analog/Digital Passive Optical Networks
CATV Networks
Subscriber Loop
Fiber Sensors
Fiber Optic Instruments etc.
Specifications
| Item | Value | |
| Channel Number | 1×2 1x3 or 2×2 | |
| Operration Wavelength(nm) | 1310,1550,1310/1550,1310/1550/1490 | |
| Operration Bandwidth(nm) | ±40 | |
| Coupling Ratio | Coupling Ratio Insertion Loss(dB) | |
| P Grade | A Grade | |
| 50/50 | ≤3.3 | ≤3.5 |
| 40/60 | ≤4.5/2.6 | ≤4.7/2.8 |
| 30/70 | ≤5.7/1.9 | ≤5.9/2.1 |
| 20/80 | ≤7.6/1.3 | ≤7.75/1.38 |
| 0/90 | ≤10.85/0.68 | ≤11.2/0.75 |
| 5/95 | ≤14.4/0.45 | ≤15.5/0.48 |
| 2/98 | ≤18.5/0.6 | ≤19.8/0.38 |
| 1/99 | ≤21.8/0.28 | ≤22.8/0.35 |
| PDL(dB) | ≤0.15 | ≤0.2 |
| Directivity(dB) | ≥50 | |
| Return Loss(dB) | ≥55 | |
