12A/12c/12D/ 12f /12m Optical Fiber Splice Tray

12A/12C/12D/12F/12M Optical Fiber Splice Tray
Specifications
1.splice tray adjustable position in forward and backward direction
2.Suitable for being installed in different kinds of optical distribution frame or cabinet
3.Compact aluminum body with electrostatic spraying surface, light structure and fine-looking appearance
4.Two core rotary distribution module is vertically arranged and can be rotated out of the box for easy operation, management and maintenance
5.Fiber guiding hoops on front and rear sides protect fibers from mechanical damage, and are arranged to ensure bending radius protection. Fiber can be inserted into guiding hoop directly, no need of interlude
6.Adapter panels are selectable with FC/SC/ST/LC type, according to requirement
7.Plug-in style adapter panels can be exchange flexibly, easy for application and configuration

* The panels accommodate FDM quantities and adapter plates as well
* This box could be used in fiber optic splice closure and terminal box
* Could be used for cable to cable splicer
* The base and cover of the box adopts "self-clip" method, which is easy and convenient to open and close
* Have a good flame retardant performance
12A(Size160*103*11)

12C(Size160*103*15)

12D(Size180*110*15)

12F(Size165*105*15)

12M-1(Size210*103*11)

12M-2(Size245*105*12)
